GROW GM861 UART/USB Interface 1D/2D Bar Code QR Code Barcode Scanner Module With Stainless Steel Enclosure White Green LED

stars, based on 0reviews
$16.80now$13.90 piece
Quantity Price
10+ $13.34
999items available
Contact Us
OR
Description





Parameter

  Performance

Sensor

  CMOS

Scan Mode

  640*480

Indicator Light

  Green lightas read successfully


Read Code Type

1D: EAN-13, EAN-8, UPC-A, UPC-EISSN, ISBN, CodaBar,Code 128,

Code93, ITF-14, ITF-6, Interleaved 2 of 5,Industrial2of5,

Matrix2of5, Code 39,Code11, MSI-Plessey,

GS1 Composite,GS1-Databar (RSS)

2D: QRCode, DataMatrix, PDF417

GM861

Reading Distance


  5-30cm

Contrast*

>25%

Scan Angle**

Roll:360°Pitch:65°Yaw:65°

Viewing Angle

67°(Horizontal)53°(Vertical)

Accuracy of reading*

≥10mil


Mechanical/electrical Parameters:

Parameter

  Performance

Interface

TTL-232/USB

Size(mm)

  External diameter: 28mm Internal diameter: 25mm

  Height: 15mm thread M25

Weight

25g

Prompting mode

LED Indicator

OperatingVoltage

3.3V

Operation Current

70mA(Max)

Standby Current

≤6mA(Typical)

Startup time

≤250mS (Typical)



·Provide User Manual

·CE Certificate


You can download the GM861 user manual from this website link:

GM861 video on Youtube: https://youtu.be/h6O3mDBp5ew




Size&Interface Definition

External diameter: 28mm, Internal diameter: 25mm, Height: 15mm, Thread M25


Brand Name:
grow
Model Number:
GM861
Operating Voltage:
3.3V
Operating Current:
70mA
Size:
Diameter 28mm
Weight:
25g
Serial Baud Rate(UART):
57600
Scan Mode:
640*480
