New Design G15 Capacitive Fingerpirnt Cabinet Lock
·Fingerprint capacity: 100
·Power supply: 4*AA battery ·Stand-by mode current: less than 9 uA
User Manual For G15
Press shortly the SET button, and hearing the music, the indicator lightened,then press finger on recognition area for twice for fingerprint,fingerprint register successful when hearing music.Fingerprint can be registered continuously.
Long press SET button, hearing music and “Di” long beep means fingerprint deleted successfully, and back to factory default. Any fingerprint can be used when factory default, and this function disabled after fingerprint registered.
Press finger both on recognition area and touch area in the mean time,then indicator will be lighten, if fingerprint passed, door will be opened successfully when hearing music ,closed and locked automatically after 5s.
1.Any fingerprint can be used when factory default, and this function disabled after fingerprint registered.
2.Emergency power: When there is no electricity, plug the emergency power supply to DC5V charge pal.
3.Induction area: the peripheral of fingerprint collecting surface is finger induction area
